How to Repair Windshield Washer?

Without windshield wipers, we would hardly be able to drive safely, especially during the winter and autumn periods. This device removes water, snow, ice, and dirt thrown by the wheels of the vehicle in front, thus providing us with the necessary visibility.

windshield wiper

Almost all motor vehicles, including cars, trucks, buses, locomotives, cabin boats, as well as some aircraft, are equipped with accessories, which are usually part of the mandatory equipment.

If you are experiencing any problem with your car, taking the help of a mechanic is advisable; however, for the improper functioning of wiper blades and windshield washers, you can DIY it.

Windshield washers are known to be highly reliable. Whenever they stop working or technical malfunction, it is probably because of a blocked nozzle or failed pump. However, these problems are easily fixable.

What tools do you need to fix Windshield Washer?

Before starting, you would be required to have a complete tool kit with the following instruments.

  • Screwdriver
  • Air compressor
  • Impact wrench
  • Adjustable wrench
  • Safety tools and gear such as glasses, gloves, and a light
  • Wrench set
  • A voltage tester and pin are required to unblock the nozzle.

What materials do you need to fix Windshield Washer?

  • Waterproof grease
  • Windshield wiper fluid and washer pump, which enables the washer fluid

How to make windshield washer fluid?

To make alone windshield washer fluid you will need to mix 3/4 gallon distilled water with 4 cups of white vinegar. If it is cold you will need to add more vinegar to prevent fluid overnight freezing.

You can fix your windshield issues and maintain your car with the following steps.

Inspect the fuse

Before starting, you need to find a soft spot to park your car and begin the operation. Start working on the washer of the window and look out for sounds that indicate the rapid rotating sound of the pump. If no sound is heard, then address the fuse box. If the fuse appears to be blown, it is probably because of the failed pump motor, which needs instant maintenance. If the fuse blows up again, it is time to change the engine completely.

Is there a fuse for the windshield washer pump?

To locate the fuse for the windshield washer pump you need to look in the power distribution center and or you can check in the owner’s manual exact location of the fuse. Please see the video below on how to locate the fuse for the windshield washer pump:

Find the fluid body and pump.

The washer pump is located inside the washer fluid reservoir or in proximity to it. This is seen in most of the new automobile manufacturers. You can quickly identify the mounted reservoir by following the windshield fluid pipe. After locating the washer hose, the access is trouble-free if the engines are found and mounted in the reservoir. However, some of the automobile manufacturers have mounted the reservoir inside the front frame. Take out the wheel and plastic frame present between the fender and the engine for complete entry and approach the reservoir and the pump.

Why isn’t my windshield wiper fluid coming out?

If your wiper fluid does not come out, then you need to clear the clogged windshield washer nozzle with a pin. This is the most common problem when windshield wiper fluid does not come out.

How to unclog windshield wiper nozzles?

Clean blocked windshield washer nozzles with the help of a narrow pin and used the compressed air to put pressure for the removal of particles in the previous direction through the pipe.

Let us see now in detail how to fix a windshield washer that won’t spray:

If you feel that the pump is doing well, But there’s hardly any fluid, then it is confirmed that the windshield washer beak is completely congested.

Check the washer hose from the beak and take it back to the tank after lifting the hood. You may also come across a plastic spiked adapter or a directional check valve. Try dislodging the tubing and check if the washer is working again. If the fluid in the tiny amount is spewing, then nozzles are impassable. You need to take out the piece and clean it properly by inserting the pin and making space for the dust and particles to come out. Push pressure to blow the blockage down towards the pipe and out at the dislodged and disconnected end.

Once pressure has been applied, check for the power. Suppose the fuse is perfectly operational, but the pump is unable to perform. In that case, you need to disengage the connector at the pump and identify strongly with the help of a voltmeter. Once the washer switch has been turned on, it should ideally be located at 12 V. If you cannot listen to the pump’s sound and the fuse working well, then the fault is likely because of an inefficient electric connection at the pump. It may even be because of a faulty pump.

Afterward, try removing the pump wire connector and take help from another set of hands to operate the pump switch. This would help you check the power at precisely 12 volts using a digital meter located at the connector. If there is no voltage detected, then the washer switch or the wiring are equipped with problems. This indicates another set of issues within the vehicle that needs proper mechanical attention. If the voltage is identified and detected, you need to coat the terminals after cleaning them with the help of the dielectric silicone grease.

Try restoring the pump.

It will function properly if the central problem has been resolved; however, you need to replace the pump if it is still not working efficiently. Typically, pump failure is associated because of chronic and repeated motion movements. The motor fails to work correctly and deliver output if it runs with the reservoir being empty. So to acquire maximum results, you need to make sure that the reservoir is in total capacity to avoid replacing it.

How to replace the windshield washer pump?

To replace a windshield washer pump you need first to drain the container. Then, you need to remove the electrical connection (just flips off) and then remove the output of the pump. In the next step, you need just to replace the old pump with a new one like in the video below.

If the situation has reached a level where the pump is asking to be replaced, then you need to follow the instruction guideline mentioned with the new washer pump for installation.

Identify auto parts store to receive a suitable and appropriate fitting and not an all-inclusive style replacement. You can contact the dealer directly if it is not available. You can remove the washer pump by removing the recruiting clips and lifting out the whole unit if the reservoir is mounted inside the engine compartment. If The reservoir is present in the wheel well, then you can easily detach the pump. With the help of a rubber loop, some pumps join together while others are held using retaining rings or fasteners.

How much does it cost to replace the windshield washer pump?

< robust>The overall cost to replace the windshield washer pump is between $70 and $120.The labor cost will be between $40 and $60, while the cost of the parts is between $30 and $60.

In the end, if all these troubles you have during the cold months, you will maybe need to unfreeze windshield wiper fluid.

How to unfreeze windshield wiper fluid?

To unfreeze windshield wiper fluid, you can put your car in the warm garage or any warmer place. Then, when the outside temperature is high, your fluid will flow without a problem. Do not try to use some tools or devices to unfreeze windshield wiper fluid and avoid any damage.

Dealing with constant maintenance for your vehicle can be strenuous and expensive. Some of these frequent maintenance demands an extra set of an investment financially and mentally. It is better to take care of these precious possessions and evaluate them quickly rather than spend endless dollars on essential maintenance.
